ONKYO DRS22
Instrukcja Obsługi

Listening to the Radio
There are two ways to select radio stations: � Manual tuning � Presetting radio stations then selecting the preset channels
FM MODE

INPUT 5/� PRESET MEMORY TUNING/PRESET 4/¢

Tuning Manually

Tuning in a weak frequency (only for FM stations)
if the signal is sufficiently strong.

When you tune in a stereo FM station, the FM ST indicator lights up

1

Unit

Press INPUT 5/� repeatedly to select the band (FM or AM).
e.g. When FM is selected. If the signal is weak, you may not be able to tune to the station. In this case, press FM MODE. The FM ST indicator and AUTO goes off. Then select the station to which you want to listen. (At this time, the station will be in mono and interstation noise will be heard.) Unit Only

Note
You can also select the band with the remote controller. See next page.

2

Unit only

Press and hold TUNING/PRESET 4/¢ for about 0.5 seconds.
Appears when a broadcast is received.

Presetting Radio Stations
� When the band is FM Auto tuning starts. The frequency changes in 50 kHz steps. When a broadcast is received, scanning stops and the frequency flashes in the display. � When the band is AM The frequency changes as follows: � (North American and South American models) In 10 kHz steps � (Other models) In 9 kHz steps When you release the button, the frequency stops changing and flashes in the display. You can preset up to 30 stations.

1 2
Unit only

Tune in the radio station you wish to preset (see steps in the left column of this page). Press PRESET MEMORY.
The MEMORY indicator lights and the preset number starts flashing in the display.

3

While the frequency is flashing (for about 5 seconds), press TUNING/ PRESET 4/¢ to change the frequency.

3

While the MEMORY indicator is lit (for about 8 seconds), press TUNING/PRESET 4/¢ to select the preset number.

� The frequency changes each time you press TUNING/PRESET 4/¢. � You can change the frequency as long as the frequency in the display is flashing. Each press of either button causes the frequency to flash for about 5 seconds.

4

Press PRESET MEMORY.
The radio station is registered to the preset channel. To register another preset station, repeat steps 1 to 4.

38
