8.3 REMOTE CONTROL
1 2 3 4 5 6
CD TUNER PHONO STANDBY / ON AMP CD TUNER TAPE

8 9

TAPE SELECT

2
DECK

7

3

DECK

I

II

1 TAPE ¡

0 = ~

4
DISC SELECT

¢

7

CD

3

_
STATION

+
TUNER

+
VOLUME

7

TAPE 1

TAPE 2

LINE

STEREO AMPLIFIER REMOTE CONTROL UNIT

�

1 CD POWER button
Switches CD player power STANDBY/ON.

8 TUNER POWER button
Switches TUNER power STANDBY/ON.

2 AMP POWER button
Switches the amplifier power STANDBY/ON.

9 TAPE POWER button
Switches the cassette deck power STANDBY/ON.

3 TAPE SELECT button
Selects the cassette No. (1 to 6) for a multi-cassette changer.

0 TAPE operation buttons
2, 3 : Playback in the direction of the arrows. 7 : Stop 1, ¡ : Tape fast forward/reverse.

4 DECK II button
To operate Deck II, press this button before pressing the operating buttons. Also, when using a single deck, press this button before pressing the operating buttons.

- CD player operation buttons
4 ¢ 7 3 : Returns you to the start of the current track (Track search). : Takes you to the start of the next track (Track search). : Stop : Play

5 DECK I button
To operate Deck I, press this button before pressing the operating buttons.

6 DISC SELECT button
Press this to select discs on a multi or twin tray compact disc player.

= STATION +, � buttons (TUNER) ~ VOLUME +, � buttons
Calls each station number in sequence.

7 Input selector buttons
Use to select the playback source. CD : For compact disc playback with a CD player. TUNER : For AM or FM broadcast reception with a tuner. PHONO : For record playback with a turntable. TAPE 1 : For playback with a cassette deck or MD recorder connected to the TAPE 1/MD terminals. TAPE 2 : For playback with a cassette deck or adaptor connected to the TAPE 2 MONITOR terminals. LINE : For playback with a component connected to the LINE terminal.

+ ........................................................... Increases the volume.
� ......................................................... Decreases the volume.

NOTE: When the accessory remote control unit is used to operate other PIONEER components with the � mark, it cannot be used to operate functions which do not correspond to the functions listed on the remote control unit.
