KENWOOD AR404
Instrukcja Obsługi

AR-404/KRF-A4030/A4030E/A4030-S
CONTENTS / ACCESSORIES / CAUTIONS
Contents
CONTENTS / ACCESSORIES / CAUTIONS............. 2 CIRCUIT DESCRIPTION ............................................3 ADJUSTMENT ............................................................6 PC BOARD ................................................................ 7 SCHEMATIC DIAGRAM .......................................... 11 EXPLODED VIEW ....................................................20 PARTS LIST..............................................................21 SPECIFICATIONS ....................................................27

Accessories
FM indoor antenna (1) (T90-0836-05) AM loop antenna (1) (T90-0852-05) Batteries (R06/AA) (2) AC plug adaptor (1) (E03-0115-05)

Remote control unit (1) (A70-1266-05): RC-R0709........KPMX (A70-1267-05): RC-R0708........E1E2E3

*Use to adapt the plug on the power cord to the shape of the wall outlet. (Accessory only for regions where use is necessary.)

Cautions Resetting the Microcomputer
If the microcomputer may malfunction (unit cannot be operated, or shows an erroneous display) if the power cord is unplugged while the power is ON, or due to some other external factor. If this happens, execute the following procedure to reset the microcomputer and return the unit to its normal operating condition. For U.S.A. and Canada Unplug the power cord from the wall outlet, then plug it back in while holding down the POWER key. Except for U.S.A. and Canada With the power cord plugged in, turn the POWER key OFF. Then, while holding down the ON/STANDBY key, press the POWER key. � Please note that resetting the microcomputer will clear the contents of the memory and returns the unit to the state it was in when it left the factory.

2
