AVD-C70ES
2-3. Track/Layer Jump Track/Layer Jump FWD R.Lj L0>L1 REV L.Lj L1>L0 Fine FWD U.Fj L0>L1 Fine REV D.Fj L1>L0 Dirc FWD Dirc REV Dirc FWD Dirc REV
2-5. EEPROM Write Adjust EEPROM Write Adjust 1. 2. 3. 4. 5. 6. Focus Focus Trk. ������ Trk. EQ Offset Gain Offset Coarse Gain Boost
1. 1Tj 2. 1Tj 3.500Tj 4.500Tj 5.10kTj 6.10kTj 7.20kTj 8.20kTj
0.All Servo Off 0. All Servo Off Exit: RETURN On this screen, track jump, etc. can be performed. Only for the DVD dual layer disc, the focus jump and layer jump are displayed in the right field Exit: RETURN On this screen, each item can be adjusted automatically. Select the desired number [1] to [10/0] from the remote commander, and selected item is adjusted automatically.
[1] 1Tj FWD : 1 track jump forward. [2] 1Tj REV : 1 track jump reverse. [3] 500Tj FWD: 500 track jump (fine search)forward. [4] 500Tj REV : 500 track jump (fine search) reverse. [5] 10kTj FWD: 10k track jump (direct search) forward. [6] 10kTj REV : 10k track jump (direct search) reverse. [7] 20kTj FWD: 20k track jump (direct search) forward. [8] 20kTj REV : 20k track jump (direct search) reverse. [10/0] : All servo off.
2-4. Non EEPROM Write Adjust Non EEPROM Write Adjust 1. 2. 3. 4. 5. 6. Focus Focus Trk. Trk. Trk. EQ Offset Gain Offset Coarse Offset Fine Gain Boost
[1] Focus Offset : Adjusts focus offset. [2] Focus Gain : Adjusts focus gain. [3] TRK. Offset : Adjusts tracking offset of the RF amp
(IC001) side. [5] TRK. Gain : Adjusts track gain. [6] EQ Boost : Adjusts amount of boost of equalizer. [10/0] : All servo off. 2-6. Memory Check Display images are shown as follows, and all two screens are able to switch by the O key (UP) or o key (DW). EEPROM Data 1/2 CD Focus Gain xx Trk. Gain xx Focus Offset xx Trk. Offset xx EQ. Boost xx PI Level xx Fcs. Balance -Jitter xx xx Mirror Time xx FE Level -Traverse Lv1. -Next:DW Default:CLR SL L0 L1 xx xx xx xx xx xx xx xx xx xx xx xx xx xx xx xx -- -xx -- -xx xx xx xx -xx -- -xx -- -Exit:RET
0.All Servo Off
Exit: RETURN On this screen, each item can be adjusted manually. Select the desired number [1] to [10/0] from the remote commander, and current setting for the selected item will be displayed, then increase or decrease numeric value with the O key or o key. This value is stored in the EEPROM. If CLV has been applied, the jitter is displayed for reference for the adjustment.
EEPROM Focus Trk. Focus Trk. EQ.
Data 2/2 Gain Gain Offset Offset Boost
CDRW DVDRW xx xx xx xx xx xx xx xx xx xx
[1] Focus Offset : Adjusts focus offset. [2] Focus Gain : Adjusts focus gain. [3] TRK. Offset : Adjusts tracking offset of the RF amp
(IC001) side.
[4] TRK. Offset : Adjusts tracking offset of the DSP (IC401)
side. [5] TRK. Gain : Adjusts track gain. [6] EQ Boost : Adjusts amount of boost of equalizer. [10/0] : All servo off. Next:UP Default:CLR Exit:RET
On this screen, current servo adjusted data stored in the EEPROM are displayed. The adjusted data are initialized by pressing the [CLEAR] key, but be careful that they are not recoverable after initialization. Before clearing the adjusted data, make a note of the set data. This screen will also appear if [0]-All is selected in the Drive Auto Adjustment. In this case, default setting cannot be made.
