4-2. Power Supply Voltage Adjustment
4-2. Power Supply Voltage Adjustment
Be sure to adjust the power supply voltage after replacing the switching regulator. Adjust the power supply voltage of the optional power unit (BKDS-PV3291) in the same procedure. Equipment Required � Digital voltmeter � Adjustment screwdriver n Use the equipments after calibration. Preparation 1. Remove the top panel. (Refer to �2-1. Removal of Cabinet�.) 2. Insert the power supply unit to be adjusted into the slot. (Refer to Section 1-6.) n Insert the power supply unit in the inner slot for adjustment.
Power supply unit
BVS-V3232
4-3(E)
|
|
 |
> |
|
