2-9. Using the Extension Board
2-9. Using the Extension Board
The extension board is provided with the FVS-P1000 for checking and adjusting the processor board. . Extension board (EX-632): . Extension board (EX-670): A-8320-763-A A-8320-764-A For extending the board in front of the processor For extending the board at the rear of the processor
Extending the Front Side Board 1. 2. 3. 4. Open the door at the bottom of the unit. Loosen the four screws, and remove the front cover. (Refer to Section 2-8-1.) Open the eject levers at both ends of the board removed in the arrow direction. Holding the eject levers, pull out the board.
Eject lever
Eject lever
Board
5. Set the dip switches of the extension board according to the board extended. 6. Push in the extension board (EX-632) according to the guide rail. 7. Insert the board removed into the extension board.
Dip switches
Extension board (EX-632)
Processor board
2-36
FVS-1000 MMP1
|
|
|
> |
|
