2-2. BKLE-102

2-2-9. KY-346 Board
1. Remove the arm assembly, and then open the panel. (Refer to �1-3. Removal of Cabinet�.) 2. Disconnect the five connectors (CN1, CN2, CN4, CN5 and CN6). 3. Remove the ten screws and remove the KY-346 board.

3. Remove the KY-346 board. (Refer to �2-2-9. KY-346 Board�.) 4. Remove the twelve screws and remove the chassis.

Chassis BVWH3 � 8

BVWH3 � 8 CN4 BVWH3 � 8 CN1 CN2 CN6 KY-346 board CN5 BVWH3 � 8 BVWH3 � 8

5. Remove the three screws and remove the search dial assembly.

4. Install the new KY-346 board in the reverse order of steps 1 through 3.

Search dial assembly

2-2-10. Search Dial Assembly
1. Remove the rubber dial knob. 2. Remove one screw and remove the dial knob.
BV3 � 8

Rubber dial knob

PWH2.6 � 5

6. Install the new search dial assembly in the reverse order of steps 1 through 5.
Dial knob
