4-5. DA-136 Board Adjustment

4-5-2. D/A Video Level Adjustment
m Check the following setup menus before starting adjustment. . Check the NTSC/PAL setup. (Refer to menu No. 010 of Section 1-9-2 of the MAV-555 Installation Manual.) . Check the network setup. (Refer to menu No. 220 of Section 1-9-6 of the MAV-555 Installation Manual.) Connection
MAV-555 + BKMA-512

Setting 1. Open �782-INT VD SG R1� of the setup menu. n For details on how to use the setup menu, refer to the Operation Manual. 2. Press the VIDEO/MENU knob once.
782-INT VD SG R1
off

3. Turn the VIDEO/MENU knob and select �CB100�
VIDEO OUT* P1-A or P2-A ETHER Ethernet

(100% color-bar signal).
782-INT VD SG R1
CB100

4. Press the SET button. 5. Set �703-OUT SETUP P1� or �704-OUT SETUP P2� to �off� on the setup menu in accordance with the port that the BKMA-512 is connected to. (Refer to Section
Waveform monitor or an oscilloscope

PC

1-9-5 of the MAV-555 Installation Manual.) n The setting is not required in case of the 625-mode (PAL). 6. Turn off the main power and back on. Restart the MAV-555. n To restart the MAV-555 quickly, execute �027-FAST REBOOT� of the setup menu. 7. Press the R1 button on the PORT SELECT block of the meter panel. (Set so that the internal SG is output to the R1 port.) 8. Press the COMPOSITE button of the VIDEO INPUT SELECT block of the meter panel for at least three seconds. (The internal SG starts, and the COMPOSITE button and the SDI button are turned on.) 9. Press either the P1 or the P2 button of the PORT SELECT block of the meter panel in accordance with the port to which the BKMA-512 is connected. 10. Press the CONTROL button of the VIDEO PROCESS block on the meter panel several times, and enter the LOCAL mode. 11. Set all buttons of VIDEO, CHROMA, SETUP, and CHROMA PHASE on the meter panel to �PRESET�.

* : Connect to the VIDEO OUT P1-A or the VIDEO OUT P2-A in accordance with the port to which the BKMA-512 is connected.
