� HEAD PHONE SOCKET When you insert a headphone plug (3.5mm stereo) into the headphone socket, the sound from the speaker will automatically be muted.
� FRONT AV SOCKET Connect the AV (AUDIO/VIDEO) socket with an appropriate cable to the corresponding socket of the external equipment. Select AV mode by pressing the AV button ( ). Press the AV button twice to return to the TV mode.
� SCART SOCKET This is used to connect : a VCR, a PAY-TV decoder, a Camcoder and a video game console. In most cases, the set changes automatically to AV mode, when the VCR connected is in play back mode. If not, press the AV button ( ) on the remote control or on the front of the set. The AV symbol ( ) will be displayed on the screen with the current TV programme number. In AV mode, you can change the TV programme number with the UP/DOWN button or the NUMBERED buttons 0...9. If external equipment has an S-VHS signal output, you can also receive the S-VHS signal with an appropriate cable (e.g. with an S-VHS plug to Scart plug) by selecting S-VHS mode with the AV button ( ). NB. It is not possible to control any of the functions except the volume control and mute function in the RGB mode. External equipment must be switched off to return to the TV mode. NB. If equipment is connected to the front AV SOCKET and the SCART SOCKET, only one piece of eqiupment can be used.
Connect to Aerial
Connect to VCR RF Out Connect to VCR Aerial
