Troubleshooting
If you have any trouble using your C-1VL, check the following table for possible causes and remedies. If you still can�t resolve the issue yourself, please contact your Onkyo dealer.
Trouble No power. Possible Cause The power cord is not connected properly. The batteries are �at. The batteries are installed incorrectly. You�re not pointing the remote controller at the C-1VL�s remote sensor. The remote controller does not work. A strong light source is interfering with the C-1VL�s remote sensor. If the C-1VL is installed in a cabinet with colored glass doors, the remote controller may not work reliably when the doors are closed. The disc is upside down. The disc is dirty. Can not play a CD. Condensation has formed inside the C-1VL. The disc is nonstandard. The C-1VL is not connected properly. There is no sound. The wrong input source is selected on your amp. The digital output on the C-1VL is turned off. The C-1VL is subject to vibration. The disc is dirty. The disc is very scratched. Can not enter track numbers for memory playback. Can not start and stop memory playback. It takes a long time to locate certain tracks. The track number entered doesn�t exist on the disc. Random playback is activated. The disc is dirty. The disc is very scratched. You�re too far away from the C-1VL. Remedy Connect the power cord properly to a suitable wall outlet (page 12). Replace with new batteries (page 8). Check the batteries and correct as necessary (page 8). Point the remote controller at the C-1VL�s remote sensor (page 8). Use the remote controller closer to the C-1VL (page 8). The remote controller has a range of approximately 5 meters (16 ft.). Make sure that the C-1VL is not subjected to direct sunshine or inverter-type �uorescent lights. Relocate if necessary. Open the doors, or use a cabinet without colored glass. Load the disc with the label-side facing up (page 13). Remove the disc and clean it (page 4). Remove your discs and leave the C-1VL turned on for several hours until the condensation has evaporated. See �About CDs� on page 4. Check all connections and correct as necessary. Check your amp�s input source setting. Refer to your amp�s manual. Press the DIGITAL OUTPUT button on the C-1VL to turn on the digital output. Install the C-1VL somewhere free of vibration. Remove the disc and clean it (page 4). Buy a new disc. Enter the correct track number (page 14). Press the RANDOM button to disable random playback before starting and stopping the memory playback. Remove the disc and clean it (page 4). Buy a new disc.

CD playback skips.

The C-1VL contains a microcomputer for signal processing and control functions. In very rare situations, severe interference, noise from an external source, or static electricity may cause it to lockup. In the unlikely event that this should happen, turn off the C-1VL, wait at least �ve seconds, and then turn it back on again. Onkyo is not responsible for damages (such as CD rental fees) due to unsuccessful recordings caused by the unit�s malfunction. Before you record important data, make sure that the material will be recorded correctly.
