1-1-3.Precaution 1. Setting the Switch Unless otherwise specified, set the switches as follows and perform adjustments without loading cassette. 1. POWER switch (MA-345/346 board) .................... CAMERA 2. NIGHT SHOT switch (Lens Block) ................................ OFF (Night shot model) 3. DEMO MODE (Menu display) ....................................... OFF 4. DIGITAL ZOOM (Menu display) ................................... OFF 5. STEADY SHOT (Menu display) .................................... OFF 6. DISPLAY (Menu display) ................................. V-OUT/LCD
Yellow

7. 8. 9. 10. 11.

FOCUS switch (MF-8500) .................................... MANUAL PROGRAM AE (CF-60/61 board) .................................. Auto BACK LIGHT (CF-60/61 board) .................................... OFF PICTURE EFECT (CF-60/61 board) .............................. OFF 16 : 9 WIDE (Menu display) ........................................... OFF

2. Adjusting Procedure Adjust in the given order.

Cyan

Color bar chart standard picture trame H
Green White Magenta

Blue

Electronic beam scanning frame

Red

0 ± 0.1 msec
Magenta Yellow Green White Cyan Blue Red

CRT picture frame

AB

A=B

BA Enlargement

V Fig. b. (TV monitor picture)

Fig. a. (Video output terminal output wavefom) Difference in level

A

B

Adjust the camera zoom and direction to obtain the output wavefom shown in Fig. a and the TV monitor display shown in Fig. b.

Fig. 5-1-5.
3. Subject 1) Color bar chart (Standard picture frame) Adjust the picture frame as shown in Fig. 5-1-5. if adjustments are performed using the color bar chart. (Standard picture frame) 2) White pattern (Standard picture frame) Remove the color bar chart from the pattern box, and insert a clear chart in its place. (Do not perform zoom operations during this time.) 3) Chart for flange back adjustment Combine a white A0 size (1189 mm x 841 mm) paper to a black one, and make the chart shown in Fig. 5-1-6.

White 841 mm Black

1189 mm

Fig. 5-1-6.
Note : Use the non-reflecting and non-glazing vellum paper whose size is more than A0, and make the boundary between white and black to be smoothly flat.

5-5
