Tekstowy podgląd strony 92 (kliknij aby zobaczyć)
1-1-6. Data Processing The calculation of the DDS display and the adjusting remote commander display data (hexadecimal notation) are required for obtaining the adjustment data of some adjustment items. In this case, after converting the hexadecimal notation to decimal notation, Hexadecimal notation-Decimal notation
The lower digits of the hexadecimal notation The upper digits of the hexadecimal notation
calculate and convert the result to hexadecimal notation, and use it as the adjustment data. Table 5-1-2. indicates the hexadecimal notation-the decimal notation calculation table.
2
0 0 16 32 48 64 80 96
1 1 17 33 49 65 81 97
2 2 18 34 50 66 82 98
3 3 19 35 51 67 83 99
4 4 20 36 52 68 84
5 5 21 37 53 69 85
6 6 22 38 54 70 86
7 7 23 39 55 71 87
8 8 24 40 56 72 88
9 9 25 41 57 73 89
A (A) 10 26 42 58 74 90
B (b) 11 27 43 59 75 91
C (c) 12 28 44 60 76 92
D (d) 13 29 45 61 77 93
E (E) 14 30 46 62 78 94
F (F) 15 31 47 63 79 95
0 1 2 3 4 5 6 7 8 9 A (A) 1n B (b) C (c) D (d) E (E) F (F) Note: (
(Example) In the case that the DDS display and the adjusting remote commander display are BD (bd). As the upper digit of the hexadecimal notation is B (b), and the lower digit is D (d), the intersection �189" of the 1 and 2 in the above table is the decimal notation to be calculated.
