2-14.HARNESS PROCESSING OF THE HINGE ASSEMBLY (TRV MODEL)
[ASSEMBLING THE HARNESS CLAMP]
Attach the harness clamp to the DP-78 harness. (8P)
� Place a longer harness to the left side. � Place the shortest harness (8P) in the right side to the bottom. � Place the hooking portion of the harness clamp to the right side. � Place the harness clamp in the left of the tie band himeron that ties the three wires. � Insert the DP-78 harness in the internal groove of the harness clamp.
(12P) (6P)
Harness clamp Himeron DP-78 harness
(Left side) Hooking portion (Right side) (8P) (6P) (12P)
[INSTALLING THE HARNESS CLAMP]
Hook the two claws of the harness clamp on the hinge bracket. Then attach it to the shaft of the hinge assembly. Note: � The harness must not be pinched. � The sheet of the FP-152 flexible board must not be peeled over. Shaft Harness clamp
Hinge bracket
[HARNESS PROCESSING]
Fix the harness using the harness guide of the hinge assembly.
� While holding the harness clamp, turn the hinge upside down. � While being careful not to twist the harness, insert the longer harness (8P) into the shallow groove and insert the
Longer harness (8P) Two shorter harnesses (6P, 12P)
other harnesses (6P, 12P) to the deeper groove.
Note: � Be sure that the harnesses do not climb over the three ribs of the guide. � Be sure that the harnesses are not pinched between the harness clamp and the shaft.
[ATTACHING THE HINGE COVER (M)]
Attach the hinge cover (M) to the hinge assembly.
� Hold the harness so that the harness must not come out from the groove. � Be careful so that the hinge cover (M) must not contact with the switch of the FP-152 flexible board.
Straight in the direction of attachemnt Hinge cover (M)
Hinge assembly
[ATTACHING THE HINGE COVER (C)]
Attach the hinge cover (C) to the hinge cover (M).
� While holding the hinge cover (M) so as not to be dropped, turn the hinge cover (C) upside down. � Route the harness inside the cutout of the hinge cover (M). � Attach the hinge cover (C) straight. (Claw hooks at the four positions.) � Make an attempt to move the harness gently at the entrance/exit of the hinge assembly to make sure that the harness can move.
Hinge cover (C)
Note: � Be sure that the harness is not pinched by the hinge cover. � Be sure that the harness can move at the entrance/exit of the hinge assembly.
Hinge cover (M)
2-13
|
|
|
> |
|
