KENWOOD CD-403
Instrukcja Obsługi

Timer operations
Timer playback of CD can be started at any time using an audio timer which is available in audio stores.
This unit

21
System control cord Audio cord

Preparation

÷ Connect the power cords of the associated components so that their power can be turned ON through the audio timer. (Also, be sure to read carefully the instruction manual of the timer.)

Amplifier or receiver

12 : 00
Audio timer To wall AC outlet

1 Turn the powers of the associated components 2 Preparation
Load a disc in the CD player.
Label side

ON.

÷ If the amplifier is not connected to the CD player through a system control cord, select the "CD" input with the input selector.

9

3 Set the amplifier volume.
1 Play the disc.

2 Adjust the amplifier volume. 3 Stop the disc.

4 Set the timer ON time.
Set the timer so that it supplies power at the specified time. ÷ With some audio timer models, the power is automatically turned OFF when the timer ON time is set. With such a model, skip step 5 below.

5 Turn OFF the power output from the audio
timer.
÷ Do not touch the ON/STANDBY (POWER/ and CD player. ) keys of the amplifier ÷ When the set time comes, the disc playback starts automatically.

Notes

1. Some amplifiers cannot be used with a timer. Before using a amplifier, check it. 2. When operating the unit other than CD player using an audio timer, be sure to remove the disc from the CD player.
