CDC-3.4 PANEL VIEW-1
FRONT PANEL
1 2 3 4 5 6
Display
7
8
9
15
Disc tray
14
13
12
11 10
8
Open/Close button
This button is used to open and close the disc tray.
1 Standby/On button
9 Disc Select buttons
This button is used to set the CDC-3.4 to On or Standby. 2 Standby indicator This indicator lights up when the CDC-3.4 is in Standby mode.
3 Repeat button
These buttons are used to select discs. Playback starts automatically when a disc is selected with one of these buttons. 10 Play/pause button This button is used to start and pause playback.
11 Stop button
This button is used with the Repeat function. 4 Random button This button is used with the Random function. 5 Dimmer button This button is used to adjust the display brightness.
6 Display button
This button is used to stop playback. 12 [ ]/[ ] & Folder [ ]/[ ] buttons These buttons are used to select the previous and next tracks and to navigate folders on MP3 discs.
13 [
This button is used to display elapsed, remaining, and total time information about the current disc or track and various information about MP3 tracks. 7 Remote control sensor This sensor receives control signals from the remote controller .
]/[ ] & Folder [ ]/[ ] buttons These buttons are used for fast reverse and fast forward and to navigate folders on MP3 discs.
14 Disc Skip button
This button is used to turn the disc tray when loading or removing discs and to select discs for playback. 15 Disc tray light This light illuminates the disc tray. It comes on when the CDC-3.4 is turned on and gets brighter when the disc tray is open.
