CARD REMOTE CONTROL
Names of parts
Replacing the battery
1 Insert the tip of a pointed object A into the hole B
and pull out the battery holder to remove the lithium battery (CR2025). Remote control (back)
BAND
TAPE
CD
CD-CH
SKIP REW FF
TUNING / DISC
UP
DOWN
Battery holder
VOLUME
2 Install a new lithium battery (CR2025) with the )
side facing up in the battery holder.
1 BAND button 2 TAPE button (This button is not available with this unit.) 3 CD button 4 CD-CH button (CD changer only) 5 SKIP f/REW button 6 SKIP g/FF button 7 PS (preset) button 8 TUNING/DISC UP/DOWN buttons 9 VOLUME +/- buttons
3 Push the battery holder into the unit until it clicks.
Preparations
A lithium battery is installed in the remote control at the factory. Before you use the remote control, be sure to remove the insulating sheet by simply pulling it out. Remote control (back)
CAUTIONS
� Keep the lithium battery out of the reach of children. If swallowed, consult a doctor immediately. � To prevent a short circuit, never pinch the battery with pliers, etc.
Insulating sheet
ENGLISH
6
|
