CDJ-100S
9 Disengage the hooks on the left and right side (2 each), and
remove the loading base assy. 0 Remove the servo mechanism assy.
DISPLAY BOARD Assy 1 Remove the jog dial and the slide knob at the top of the body, and
then remove the nut (M9) and jog washer.
Jog Dial
1
LOADING BASE ASSY Nut (M9) Jog Washer
1
Slide Knob
10
SERVO MECHA ASSY
Hook
9
Hook
9 9 9 2
2 Disconnect the earth lead unit. 3 Remove the 13 screws F.
DISPLAY BOARD ASSY Earth Lead Unit
Removal of the Each P. C. Boards
TRANS BOARD Assy 1 With the slot-in Mechanism Assy removed, disconnect the
connector (CN705). 2 Remove the screw C and disconnect the cable stay. 3 Remove the seven screws D, raise front side of the TRANS BOARD assy, and remove it.
Cable Stay TRANS BOARD ASSY Screw D Screw D
3
Screw F (� 13)
2
Screw C
Caution for the time of assembly
Screw D
Turn the jog dial and check for abnormalities like uneven turning etc. Nut Tightening Torque: 8 kg · cm or less
