PULLY AND DISC CENTER HOLE ALIGNMENT
cam base unit
cam bracket (BU adjustment)
(1)
Rotate the cam and adjust to the position shown in the figure.
magnet ass�y
(2)
Check that the state is as shown in the figure.
0.5 � 2 mm disc disc pulley disc hole base unit
Note: The disc should not be fixed.
holder (disc A2)
fixed screw
bracket (BU adjustment)
tapering screwdriver magnet ass�y
(3)
Remove the Magnet ass�y.
(4)
Loosen the fixed screw by 60° to 90°, and move and adjust the bracket (BU adjustment) up and down using a tapering screwdriver so that the positions of the disc hole and disc pulley become A=B or between A:B=2:1 and 1:2.
