PITCH The playback speed (pitch) of the CD drive can be changed up to ±12.0% in steps of 0.1%. Default setting is 0. Digital signals are not output when pitch control is on. Adjusting the pitch lets you tune the CD output to a musical instrument, useful when practicing because it permits adjusting the music practice source to your instrument. When pitch is active the green PITCH indicator on the front of the CDR510 is lit and steady. Pitch settings remain when discs are changed or if the CDR510 is powered off. There are two menu controls for pitch, PITCH and PITCH ON/OFF. How to adjust the PITCH (menu control) The PITCH menu control adjusts the pitch. 1. With the CD drive selected push and release the MENU/STORE button. 2. Turn the REC LEVEL/SELECT control until PITCH is displayed.

How to turn the PITCH ON or OFF The PITCH ON/OFF menu control lets you turn the pitch on or off without changing the pitch adjustment when pitch is on. If you turn the pitch adjustment off and later, if you turn the pitch adjustment back on, the original pitch setting remains. 1. With the CD drive selected push and release the MENU/STORE button. 2. Turn the REC LEVEL/SELECT control until PITCH ON/OFF is displayed.

CD - RW ANALOG

L R

CD

3. Push and release the REC LEVEL/SELECT control. ON or OFF is displayed. 4. Turn the REC LEVEL/SELECT control to toggle between ON and OFF.

ANALOG

CD - RW

L R

CD

5. When correct push and release the REC LEVEL/SELECT control. PITCH ON/OFF is displayed again. 6. Turn the REC LEVEL/SELECT control to switch to other menu choices or press and release the CANCL/DELETE button to exit menu mode.

ANALOG

CD - RW

L R

CD

3. Push and release the REC LEVEL/SELECT control. PI is displayed. 4. Turn the REC LEVEL/SELECT control to adjust the pitch. Example display
ANALOG

CD - RW

L R

CD

5. When correct push and release the REC LEVEL/SELECT control. PITCH is displayed again. 6. Turn the REC LEVEL/SELECT control to switch to other menu choices or press and release the CANCL/DELETE button to exit menu mode.

- 36 -
