SONY CPD520GS 1
Instrukcja Serwisowa

CPD-520GS/520GST/520GST9
SERVICE MANUAL
REVISED

US Model Canadian Model
CPD-520GS Chassis No. SCC-L04N-A CPD-520GST

AEP Model UK Model
Chassis No. SCC-L04N-A CPD-520GST9

AEP Model
Chassis No. SCC-L04N-A

N3 CHASSIS
SPECIFICATIONS
Picture tube 0.25 � 0.27 mm aperture grille pitch 21 inches measured diagonally 90-degree deflection Approx. 403.8 � 302.2 mm (w/h) (16 � 12 inches) 19.8� viewing image Horizontal: Max. 1600 dots Vertical: Max. 1200 lines Approx. 388 � 291 mm (w/h) (15 3/8 � 11 1/2 inches) or Approx. 364 � 291 mm (w/h) (14 3/8 � 11 1/2 inches) Deflection frequency AC input voltage/current Power consumption Dimensions Mass Supplied accessories 100 to 240 V, 50 � 60 Hz, 2.0 � 1.0 A Max. 160 W 498 � 505 � 474 mm (w/h/d) (19 5/8 � 20 � 18 3/4 inches) Approx. 31 kg (68 lb 5 oz) See page 6 Horizontal: 30 to 96 kHz Vertical: 48 to 160 Hz Viewable image size

Resolution Standard image area

Design and specifications are subject to change without notice.

TRINITRON® COLOR COMPUTER DISPLAY
MICROFILM
