Timers
About the Timers
STANDBY/ ON
CLOCK CALL

The CR-505 has four timers so that you can turn it on and off automatically at certain times and on certain days of the week, in order to listen to, or record your favorite programs. Timers can be used to start and stop playback (Play), or to start and stop radio or LINE input recording (Rec) with an Onkyo cassette tape deck or Mini Disc recorder connected via . Timers can be set for single use (Once), in which case the timer is reset once the task has been completed, for use on a certain day every week (Every), or for a range of days (e.g., Monday through Friday).

1 4

2 5 8
--/---

3 6 9
CLEAR

TIMER

TIMER

7
10/0

ENTER
DISPLAY MODE

ENTER

SLEEP

REPEAT

Setting the Timers
The timers are set using the remote controller. You must set the clock (page 16) before you can set the timers. To use a timer to turn on the radio, you must �rst preset some radio stations (see page 25). When the CD is selected for the input source, the timer cannot be set without a disc placed on the disc tray. This avoids forgetting to load a disc.

I Timer Examples
The following examples highlight some of the ways in which you can use the timers. Timer 1: To wake up to your favorite radio station (preset #1) every morning, set as follows: PLAY�FM 1�EVERY�EVERY DAY�ON 7:00�OFF 7:30 (If you want a radio alarm only on weekdays, select �DAYS SET� instead of �EVERYDAY� and specify �MON�FRI.�) Timer 2: To record a radio program (preset #2) on the cassette tape deck only this Sunday, set as follows: REC�FM 2�TAPE�ONCE�SUN�ON 21:00�OFF 22:00 (You need an Onkyo cassette tape deck to do the recording.)

1 Press the [TIMER] button repeatedly to
select TIMER #1, #2, #3, or #4, and then press the [ENTER] button.

I Timer Overlap
If two or more timers are set to the same ON time, the timer with the lowest number has priority. For example, if Timer #1 and Timer #2 are both set to an ON time of 7:00, Timer #1 has priority and Timer #2 is ignored. Timer 1: 07:00 - 13:00 (This timer has priority.) Timer 2: 07:00 - 12:30 If the settings of two timers overlap, the earlier timer has priority. Timer 1: 9:00 - 10:00 Timer 2: 8:00 - 10:00 (This timer has priority.) Notes: � The timers work only if the CR-505 is in Standby mode. If the CR-505 is on when a timer is supposed to start playback or recording, nothing will happen, so be sure to switch the CR-505 to Standby mode. � While a timed recording task is in progress, the output of the CR-505 is muted. To hear what�s being recorded, press the [MUTING] button to cancel the Mute function. Press it again to mute the CR-505.

2 Use the Up/Down [ 3 Use the Up/Down [

]/[ ] buttons to select �PLAY� or �REC,� and then press [ENTER]. ]/[ ] buttons to select the input source, and then press [ENTER].
For timed playback you can select any input source. For timed recording you can select AM, FM, or LINE. If you select AM or FM, use the Up/Down [ ]/[ ] buttons to select a preset, and then press [ENTER].

When you select �REC� in step 2: Use the Up/Down [ ]/[ ] buttons to select either �TAPE� or �MD� for the recording medium, and then press [ENTER].

4 Use the Up/Down [

]/[ ] buttons to select �ONCE� or �EVERY,� and then press [ENTER].
ONCE: For single use. EVERY: For weekly use.

5 Use the Up/Down [
28

]/[ ] buttons to select one of the following options, and then press [ENTER].
