AIWA CRDS555
Instrukcja Serwisowa

ELECTRICAL PARTS LIST -4/4
� Regarding connectors, they are not stocked as they are not the initial order items. The connectors are available after they are supplied from connector manufacturers upon the order is received.
CHIP RESISTOR PART CODE

Chip Resistor Part Coding

88
A
Resistor Code Value of resistor Chip resistor
Dimensions (mm)

Figure

Wattage 1/16W 1/16W 1/10W 1/8W

Type 1005 1608 2125 3216

Tolerance 5% 5% 5% 5%

Symbol CJ CJ CJ CJ

Form
L W

L 1.0
t

W 0.5 0.8 1.25 1.6

t 0.35 0.45 0.45 0.55

:A Resistor Code : A
104 108 118 128

1.6 2 3.2
