4-3.

HOW TO INSTALL THE GEAR (MODE 2)

1 Align the mark on the rotary encoder (S701) with the projection of the assy. 2 Check that the cam (BU U/D) can not be rotated in the direction of arrow. 3 Install the gear (mode 2).

rotary encoder (S701) gear (mode 2)

cam (BU U/D)

mark

projection � bottom view � front �

chassis

4-4.

HOW TO INSTALL THE GEAR (MODE CAM)

1 Slide the shaft in the direction of arrow. 2 Align mark A on the gear (mode cam) with mark B on the slider (mode cam) assy, then install the gear (mode cam). 3 Check that mark C on the gear (mode cam) is in alignment with mark D on the cam (gear).

shaft

mark A

gear (mode cam)

slider (mode cam) assy

mark D

mark B

mark C cam (gear)

� bottom view � front �

20
