Preparation of Use
ª Removing the transit screw
Unscrew the transit screw with a Phillips head screwdriver by rotating counterclockwise until the screw is completely removed.
ª Battery installation for Remote Control Unit
ª Connecting speakers
Connect each speaker plug to the speaker terminal. Use speakers with impedance of 4 ohms or more, since low impedance speakers may damage the unit.
ª Connecting the AC power cord
After connecting the speakers, insert the power plug into the wall outlet firmly. The STANDBY indicator on the panel will light. 1. Remove the battery compartment cover. 2. Insert three "AAA" (R03, UM-4) dry batteries. Make sure that the batteries are inserted with their positive ± and negative � poles positioned correctly. 3. Close the cover until it clicks.
ª Battery installation for memory backup
Set a new "006P" 9V battery to the terminal inside the battery compartment on the rear panel. The battery will keep the preset radio stations in memory. � Replace the battery with new one approximately every one year. When replaced, preset stations may be erased from the memory. In this case, memorize the station again.
ª Battery Replacement
If the distance required between the remote control unit and main unit decreases, the batteries are exhausted. In this case replace the batteries with new ones.
ª Precautions concerning batteries
� Be sure to insert the batteries with correct positive "±" and negative "�" polarities. � Use batteries of the same type. Never use different types of batteries together. � Rechargeable and non-rechargeable batteries can be used. Refer to the precautions on their labels. � When the remote control unit is not to be used for a long time (more than a month), remove the batteries from the remote control unit to prevent them from leaking. If they leak, wipe away the liquid inside the battery compartment and replace the batteries with new ones.
Memory Backup Battery Compartment To AC Outlet Transit Screw Speaker Plugs
� Do not heat or disassemble batteries and never dispose of old batteries by throwing them in a fire.
This equipment draws nominal nonoperating power from the AC outlet with its POWER switch in the OFF position.
Obs! nätströmställaren skiljer ej fela apparaten från nätet.
-5-
|
|
|
> |
|
