PIONEER DEH-3100UB/XS/ES
Instrukcja Obsługi

Section

02

Operating this unit
Refer to Scanning folders and tracks on page 13. Refer to Pausing playback on page 13. Refer to Using Sound Retriever on page 13.

SCAN PAUSE

Playing songs on iPod
You can control and listen to songs on an iPod. ! For details about the supported iPod, refer to iPod compatibility on page 34. ! When using an iPod, iPod Dock Connector to USB Cable is required.

SOUND RETRIEVER

Notes ! To return to the previous display, press DISP/BACK/SCRL. ! To return to the main menu, press and hold DISP/BACK/SCRL. ! To return to the ordinary display, press BAND/ESC. ! If you select another folder during repeat play, the repeat play range changes to ALL. ! If you perform track search or fast forward/reverse during TRACK, the repeat play range changes to FOLDER. ! After file or folder scanning is finished, normal playback of the files begins again. ! If you do not operate functions within about 30 seconds, the display automatically returns to the ordinary display.

Basic Operations
% Plugging an iPod
1 Plug an iPod into the USB port using the iPod Dock Connector to USB Cable. Regarding the position of USB port, refer to Head unit on page 6. 2 Press SRC/OFF to select USB-IPOD as a source. Playback will start.

% Fast forwarding or reversing Push and hold MULTI-CONTROL left or right. % Selecting a track (chapter) Push MULTI-CONTROL left or right. % Disconnecting an iPod Pull out the iPod Dock Connector to USB Cable.
Notes ! Read the precautions for iPod in the following section. Refer to page 34. ! While iPod is connected to this unit, PIONEER (or (check mark)) is displayed on the iPod. ! If an error message is displayed, refer to Error messages on page 29. ! When the ignition switch is set to ACC or ON, the iPod�s battery is charged while the iPod is connected to this unit. ! While the iPod is connected to this unit, the iPod cannot be turned on or off. However when the control mode is set to IPOD, you can turn the iPod on or off. ! Before connecting the dock connector of this unit to the iPod, disconnect the headphones from the iPod. ! The iPod is turned off about two minutes after the ignition switch is set to OFF.

16

En
