DEH-P400,P4000,P4050
Audio Adjustment
Equalizer Curve Fine Adjustment
You can adjust the center frequency of each equalizer curve band (LOW/MID/HIGH) and the Q factor (curve characteristics).
Level (dB)
Q=2N Center frequency
Q=2W Frequency (Hz)
1. Press the AUDIO button for 2 or more seconds to select Equalizer Curve Fine Adjustment. 2. Press the AUDIO button to select the desired band for adjustment. 3. Select the desired frequency with the 2/3 buttons.
LOW: 40 + 80 + 100 + 160 (Hz) = = = MID: 200 + 500 + 1K + 2K (Hz) = = = HIGH: 3K + 8K + 10K + 12K (Hz) = = =
4. Select the desired Q factor with the 5/� buttons.
2N + 1N + 1W + 2W = = =
Loudness Adjustment (LOUD)
The Loudness function compensates for deficiencies in the low and high sound ranges at low volume. You can select a desired Loudness level.
1. Press the AUDIO button and select the Loudness mode (LOUD) in the Audio Menu. 2. Switch the Loudness function ON/OFF with the 5/� buttons. 3. Select the desired level with the 2/3 buttons.
LOW + MID + HI = =
