4-2 Playback Procedures
This section describes the following types of playback which the unit can carry out: � Normal playback Playback at normal (�1) speed � Playback in jog mode Variable speed playback, with the speed determined by the speed of turning the search dial � Playback in shuttle mode Variable speed playback, with the speed determined by the angular position of the search dial � Playback using the capstan override function The playback speed is adjusted temporarily according to the angular position of the search dial, to align the playback phase with that of another VTR.
Chapter 4 Playback

If you play back to the end of the tape The tape is automatically rewound, and stops. When using the Dolby noise reduction system When using an analog Betacam cassette, you can use Dolby C noise reduction for audio playback. To activate the Dolby noise reduction system, set the DOLBY NR switch on the subsidiary control panel to ON.

4-2-2 Playback in Jog Mode
In jog mode, you can control the speed of playback by the speed of turning the search dial. The playback speed range is ±1 times normal speed. To carry out playback in jog mode, use the following procedure.

4-2-1 Normal Playback
Insert a required cassette beforehand.
For details of how to insert a cassette, see Section 3-3-2, �Inserting and Ejecting Cassettes� (page 3-4).

To start playback Press the PLAY button. Playback starts, the servo locks, and the SERVO indicator lights. To stop playback Press the STOP button.
Cassette compartment

1 1,2,3
1
Press the JOG button or search dial so that the JOG button is lit. Pressing the search dial toggles between jog mode and shuttle mode.

2

Turn the search dial in the desired direction, at the speed corresponding to the desired playback speed. Playback in jog mode starts.

3
STOP button PLAY button

To stop playback in jog mode, stop turning the search dial. The search dial function to toggle between jog mode and shuttle mode every time being pressed can be prohibited by changing the setting of extended menu item 101.

4-2

Chapter 4

Playback
