Chapter 13: Using the effects
iTIP : If you selected Global effects for both EFFECT A and B, you may want to select
STEREO
1 MIXED
or 2 STEREO PAIRS If you have selected Insert effects for either EFFECT A or B or PAIRS. both, you may want to select 2 STEREO PAIRS PAIRS.
Routing effect return signals to THRU MIX channels
You can send effect return signals that have been switched as analog input signals to the THRU MIX channels in the mixer section to mix them with the TRACK MIX channel signals (track playback). Follow the steps below to send the effect return signals to the mixer section. 1. Press the THRU [F2] key in Assign mode. 2. Select the analog inputs to which the effect return signals are routed, and select as their destination.
THRU MIX
Example: If you selected
2 STEREO PAIRS in Assign FXB RTN-L FXB RTN-R to THRU MIX RTN-L, RTN-R, MIX.
mode, route
FXA RTN-L FXA RTN-R RTN-L, RTN-R,
Setting the effect send level
You may set the AUX send level of the TRACK MIX channels to which you wish to apply effects in Mixer mode. The operation will differ slightly depending on whether you selected Global effects or Insert effects.
s If you selected Global effects
1. Select TRACK MIX channels in Mixer mode, and adjust the AUX SEND-A or AUX SEND-B level of the channel to which you wish to apply effects. AUX SEND A signal is sent to EFFECT A, and AUX SEND B signal is sent to EFFECT B. At this time, you can check the output level of AUX SENDs A/B using level meters SA/B. If the level is too high, adjust it using the channel SEND MASTER and AUX SEND-A/B parameters.
1
You can check the output level of AUX SEND A/B using the meter 1. 2. Recall the AUX-A PRE/POST and AUX-B PRE/POST parameters to select whether the signals sent to EFFECT A/B are routed from the pre-fader or post fader.
