Strona główna >> ONKYO >> DPS7.3 Instrukcja Obsługi

 0 szt. w koszyku

ONKYO DPS7.3
Instrukcja Obsługi


Tweetnij o tym produkcie a dostaniesz $1.00 rabatu!
  • Plik do pobrania
  • Format PDF
  • Kompletna instrukcja
  • Język: English
Cena: $4.99

Opis ONKYO DPS7.3 Instrukcja Obsługi

Kompletna instrukcja obsługi w formie pliku PDF. Plik PDF zostanie dostarczony na Twój adres email po jego zakupieniu.

Instrukcje obsługi (czasami nazywane także podręcznikiem użytkownika) opisuja funkcje i sposób działania danego produktu.

Instrukcja jest dostępna w następujących językach: English

Plik nie jest jeszcze gotowy
Musisz najpierw dokonać zakupu.

Recenzje produktu
Dla tego produktu nie napisano jeszcze recenzji!

Tekstowy podgląd strony 50 (kliknij aby zobaczyć)
Adjusting Audio and Video Settings
Adjusting the Video Quality
You can adjust any or all of the following picture quality factors:

Prog. Motion
When using progressive scan, this adjusts the motion and still picture quality.

I Adjusting the picture quality settings � To create your own setting (2)
1 Use the cursor button (3) to select [Start] then press ENTER.

PureCinema
When watching DVD movies, PureCinema optimizes the picture quality. The default setting is Auto1, but if the picture appears unnatural, then set to Auto2, On or Off as desired and adjust the Prog. Motion setting (see above). See PureCinema in the Glossary starting on page 160.

Video Memory Select Video Setup

YNR
Adjusts the amount of noise reduction (NR) applied to the Y (brightness) component.

CNR
Adjusts the amount of noise reduction (NR) applied to the C (colour) component.

2 Use the cursor button (�) to select [Video Setup] and press ENTER. 3 Press DISPLAY.
Prog.Motion PureCinema YNR CNR MNR BNR Sharpness High Sharpness Mid Memory Page 1/2 fast slow Auto1 Auto2 On Off Off Off Off Off soft soft Off 1 23 max max max max fine fine

MNR (Mosquito Noise Reduction)
Adjusts the amount of noise reduction applied to the mosquito noise (video artifacts on the edge of the image resulting from MPEG compression).

BNR (Block Noise Reduction)
Adjusts the amount of noise reduction applied to the block noise.

Sharpness High
Adjusts the sharpness of the high-frequency (finely detailed) elements in the picture.
Detail White Level Black Level Black Setup Gamma Hue Chroma Level Chroma Delay Memory Off min min

Page 2/2 max max max 7.5 IRE + red 23 max +

Sharpness Mid
Adjusts the sharpness of the mid-frequency (less detailed) elements in the picture.

0 IRE � green min � Off 1

Detail
Adjusts how sharp edges appear in the picture.

White Level
Adjusts the intensity of white in the picture.

4 Use the cursor buttons (5/�) to select the setting and use the cursor buttons (2/3) to adjust the settings.
Adjust these while a disc is playing to see the effect of changes immediately.

Black Level
Adjusts the intensity of black in the picture.

Black Setup
For correction of floating black colour.

5 To memorize the setting, select Memory 1, 2, 3, then press ENTER.
The previous setting will be erased.

Gamma
Adjusts the brightness of the darker images in the picture.

Hue
Adjusts the overall colour balance between red and green.

Chroma Level
Adjusts how saturated colours appear.

Chroma Delay
Compensates for misalignment of the Y (brightness) and the C (colour) components.

5 Use the cursor buttons (2/3/5/�) to adjust the settings.
Adjust these while a disc is playing to see the effect of changes immediately.

6 Repeat steps 4 and 5 to make adjustments to other settings.
If you would like to save the settings in the player�s memory, be sure to select either [1], [2], or [3] in the [Memory] setting to establish which memory location to save the new settings in. Please note that if you select a location where settings have already been saved, the old settings will be replaced by the new ones.

Memory Move
ENTER

Off Select

1

2

3 Check

DISPLAY

7 When you are finished making adjustments, press ENTER to establish the new settings.
Expert denotes more detailed settings. If the item is not displayed, please refer to page 42 to display it.

50
