Using the RI Dock
Setting the OSD Mode
Set the OSD (onscreen display) mode before you start using the RI Dock. 1. Plug in the AC adapter. 2. Turn on your TV and amp, and select the appropriate inputs on your TV and amp. 3. Insert your iPod into the RI Dock. 3rd generation iPod: Before inserting a 3rd generation iPod, set the OSD mode as explained in step 4.

Controlling Your iPod without the OSD
To control your iPod without the OSD, set the OSD mode to Off, and use the remote controller as explained on page 6.

Controlling Your iPod with the OSD
When the OSD mode is set to On and your iPod is inserted in the RI Dock, playlists (artists, albums, songs, genres, composers) will be displayed on your TV. � Playing Songs

4. Use the remote controller�s [MODE] button to set the OSD mode. On: Playlists (artists, albums, songs, genres, composers) are displayed on your TV, and you can navigate and select your music while looking at your TV. While this mode is selected, your iPod displays the Onkyo logo. Off: Nothing is displayed on your TV and you navigate and select your music by using your iPod�s display. Notes: � To prevent dock connector damage, don�t twist your iPod when inserting or removing it, and be careful not to knock over the RI Dock while your iPod is inserted. � Don�t use the RI Dock with any other iPod accessories, such as FM transmitters and microphones, because they may cause a malfunction. � You can�t change the OSD mode while watching an iPod slideshow or video.

1. Use the Up and Down arrow [ ]/[ ] buttons to select Playlists, Artists, Albums, Genres, Songs or Composers, and then press the [SELECT] button.

Top Menu

2. Use the Up and Down arrow [ ]/[ ] buttons and [SELECT] button to select a song, and press the Play/Pause [ / ] button to start playback. When selecting songs, use the [MENU] button to go back to the previous menu.
