4. Preparing the Flash Adjustment Box A dark room is required to provide an accurate strobe adjustment. If it is not available, prepare the flash adjustment box as given below; 1) Provide woody board A, B and C of 15 mm thickness.

woody board A (2 sheets) 400 mm

woody board B (2 sheets) 370 mm

woody board C (1 sheet) 700 mm

513 mm

513 mm

700 mm

730 mm

700 mm

Fig. 6-1-6.

2) Apply black mat paint to one side of woody board A and B. 3) Attach background paper (J-2501-130-A) to woody board C. 4) Assemble so that the black sides and the background paper side of woody board A, B and C are internal. (Fig. 6-1-7.)
woody board A

woody board B

woody board A

woody board B woody board C

Fig. 6-1-7.
