Tekstowy podgląd strony 156 (kliknij aby zobaczyć)
RC-CCR This item shows a detail of CR signal�s wiring check result between PR LSI (IC214/DPR board) and RC LSI (IC308/DPR board). 400H: 10th of CR signal (wiring between pin 108 of IC214 and pin 84 of IC308 on the DPR board) error 200H: 9th of CR signal (wiring between pin 107 of IC214 and pin 85 of IC308 on the DPR board) error 100H: 8th of CR signal (wiring between pin 106 of IC214 and pin 86 of IC308 on the DPR board) error 080H: 7th of CR signal (wiring between pin 104 of IC214 and pin 87 of IC308 on the DPR board) error 040H: 6th of CR signal (wiring between pin 103 of IC214 and pin 88 of IC308 on the DPR board) error 020H: 5th of CR signal (wiring between pin 102 of IC214 and pin 89 of IC308 on the DPR board) error 010H: 4th of CR signal (wiring between pin 101 of IC214 and pin 92 of IC308 on the DPR board) error 008H: 3rd of CR signal (wiring between pin 100 of IC214 and pin 93 of IC308 on the DPR board) error 004H: 2nd of CR signal (wiring between pin 99 of IC214 and pin 94 of IC308 on the DPR board) error 002H: 1st of CR signal (wiring between pin 98 of IC214 and pin 95 of IC308 on the DPR board) error 001H: 0th of CR signal (wiring between pin 95 of IC214 and pin 96 of IC308 on the DPR board) error RC-CCB This item shows a detail of CB signal�s wiring check result between PR LSI (IC214/DPR board) and RC LSI (IC308/DPR board). 400H: 10th of CB signal (wiring between pin 121 of IC214 and pin 70 of IC308 on the DPR board) error 200H: 9th of CB signal (wiring between pin 120 of IC214 and pin 71 of IC308 on the DPR board) error 100H: 8th of CB signal (wiring between pin 119 of IC214 and pin 72 of IC308 on the DPR board) error 080H: 7th of CB signal (wiring between pin 118 of IC214 and pin 75 of IC308 on the DPR board) error 040H: 6th of CB signal (wiring between pin 117 of IC214 and pin 76 of IC308 on the DPR board) error 020H: 5th of CB signal (wiring between pin 116 of IC214 and pin 77 of IC308 on the DPR board) error 010H: 4th of CB signal (wiring between pin 115 of IC214 and pin 78 of IC308 on the DPR board) error 008H: 3rd of CB signal (wiring between pin 112 of IC214 and pin 79 of IC308 on the DPR board) error 004H: 2nd of CB signal (wiring between pin 111 of IC214 and pin 80 of IC308 on the DPR board) error 002H: 1st of CB signal (wiring between pin 110 of IC214 and pin 82 of IC308 on the DPR board) error 001H: 0th of CB signal (wiring between pin 109 of IC214 and pin 83 of IC308 on the DPR board) error Note: If the sync signals input to PR LSI and RC LSI is having error, error is also detected on the wiring check between PR LSI and RC LSI.
DSR-300/P(E)/V1
