DCR-DVD200/DVD200E/DVD300

2-29.LB-084 BOARD (REMOVING OF THE EVF)-2

4

Visibility knob (40)

VF slide cabinet (upper) assembly To raise the VF slide cabinet (upper) assembly, insert a flat head (-) screwdriver into the position shown by the arrow. VF slide cabinet (upper) assembly
2A 1 Tapping screw (M1.7 � 3.5) 5 C

3 B

2 A

VF slide cabinet (lower)

2 Open the lock of the VF slide cabinet (lower) in the direction of the arrow A, 3 while slanting the VF slide cabinet (upper) assembly in the direction of the arrow B, 4 remove the Visibility knob (40) from the VF slide cabinet (lower), and 5 remove the VF slide cabinet (upper) assembly by sliding it in the direction of the arrow C.

VF slide cabinet (lower)

RE-ASSEMBLING THE VF SLIDE CABINET
1 VF slide assembly

2 Align the dotted portion of the VF slide assembly with the dotted line of the VF slide cabinet (lower).

VF slide cabinet (lower)

When re-assembling, slide the Visibility knob (40) to the fully right-end beforehand. Visibility knob (40) When re-assembling is completed, the VF slide cabinet (upper) assembly and the VF slide cabinet (lower) are assembled as shown. VF slide cabinet (upper) assembly

3 Slide the VF slide cabinet assembly up to the position in the direction of the arrow where the two claws are locked.

4 Tapping screw (M1.7 � 3.5)

VF slide cabinet (lower) VF slide cabinet (lower) Two claws

2-19
