5. NOTE ON MOUNTING SLED MOTOR
1) Push the sled motor ass�y 1 toward direction A. (See Fig. 4) 2) Tighten two screws 2 (M1.7 � 2.5).

1 Sled motor ass�y A

2 Two screws (M1.7 � 2.5)

Fig. 4
3) Raising the MD block ass�y 3 90 º with the side down. confirm that the optical pick-up 4 falls by self weight. (See Fig. 5) 4) Further, with the front side of MD block ass�y 3 up, confirm that the optical pick-up falls by self weight.
3 MD block ass�y Upper Upper

Front side

Front side Lower

Lower

4 Optical pick-up

Fig. 5

�6�
