Recording
06
Recording from a DV camcorder
VR mode Video mode HDD
You can record from a DV camcorder connected to the DV IN/OUT jack on the front panel of this recorder. Using the recorder�s remote, you can control both the camcorder and this recorder. Before recording, make sure that the audio input for the DV IN/OUT jack is setup (see DV Input on page 93).
� For best results when recording from a DV camcorder to this recorder, we recommend cueing the camcorder to the place you want to start recording from and setting the camcorder to playpause. 1 Make sure your digital camcorder is connected to the front panel DV IN/OUT jack. Also, set the camcorder to VTR mode. 2 Set up the recorder. � Use REC MODE to set the recording quality. See Setting the picture quality/recording time on page 44 for detailed information. � Make sure a recordable disc is loaded if you want to record to DVD.
HDD
DVD
3 From the Initial Settings menu, check that the DV audio input is setup as you require. See DV Input on page 93 for more on this. � Check also that the Audio In settings for External Audio and Dual Mono Recording are as you want them (see Audio In settings on page 92).
CLEAR
4
Press HOME MENU and select �DV Record� from
ENTER
HOME MENU RETURN
the menu. � DV recording only works when the digital camcorder is in VTR mode with a tape loaded. 5 Select �Record to HDD� or �Record to DVD� to record to the hard disk drive or a recordable DVD respectively. 6 Find the place on the camcorder tape that you want to start recording from. For best results, pause playback at the point from which you want to record. � Depending on your camcorder, you can use this recorder�s remote to control the camcorder using the ,,, , , and buttons.
REV SCAN
PLAY
FWD SCAN
PAUSE
STOP
STEP/SLOW
REC MODE
ì
Important � The source signal must be DVC-SD format � Some camcorders cannot be controlled using this recorder�s remote. � If you connect a second recorder using a DV cable, you cannot control the second unit from this one. � You can�t control this unit remotely from a component connected to the DV IN/OUT jack. � You can�t record date and time information from DV cassette. � You can�t record copy-protected or copy-once material. � During DV recording, if a part of the tape is blank, or has copy-protected material on it, this recorder will pause recording. Recording will restart automatically when there is a recordable signal.
7 Use the / (cursor up/down) buttons to select �Start Rec� and press ENTER.
Stop 1.02.22 Control with these buttons
Stop
Start Rec Pause Rec Stop Rec HDD SP (2h00m/DVD) Remain 1h40m
� Recording is automatically paused if the recorder detects no signal, or a copy-protected signal. Recording restarts when there is a non-copyprotected signal.
53
En
|
|
|
> |
|
