Speaker setting
DVR-8100 (EN)

The ideal listening position for 6-channel surround playback is the point at equal distance from all speakers. By setting the delay time for the center and surround speakers, this item realizes the ideal listening position virtually. (The center and surround speakers can be set as if they are laid out on the dotted line circle shown below.)
Ideal center speaker position

How to set the delay time
Delay time setting sets the delay time converted to the distance from the speaker to the listening position. The front speakers (L/R) can be adjusted between 40 feet (12 m) and 3 feet (0.9 m). The range which can be set for the center speaker (C) and the surround speakers (LS/RS) differs according to the setting for
Ideal surround speaker position

L

SW

C

R

L

C

R

S L

S

S R

the front speakers. A longer distance than for the front speakers can not be set.

Delay time setting
This operation must be performed following the adjustment of the speaker level setting on page 51. 1 Press SETUP key.
AUTO TUNED ST. CLIP L SW C LFE S RS R

Blinks

Operations

SETUP

LS

Active EQ./ SOUND

Return to the original display is made when no operation is performed for about 5 seconds.
Feet indication Meter indication

2 Press the TRIM (5/�) keys to select the speaker distance.

5
TRIM

AUTO TUNED

ST. CLIP L SW C LFE R

�
3 Press SETUP key.
SETUP

LS

S

RS

The process advances to center speaker adjustment when the SETUP key is pressed.
AUTO TUNED ST. CLIP L SW C LFE R

Active EQ./ SOUND
LS

S

RS

4 Press the TRIM (5/�) keys to select the speaker distance.
AUTO TUNED ST. CLIP L C SW LFE R

5
LS

S

RS

TRIM

�

Repeat 3 and 4 in the same way to adjust the surround speakers.
