DV-S757 DISASSEMBLING PROCEDURES-1
1. Optical pick-up are parts which are easy to receive damage with static electricity. Therefore, in case reassembly mechanism, take the measures against static electricity. 2. The number of ( ) in the explanatory note and in the figure shows Ref. No. of the exploded view.
How to remove the DVD mechanism from chassis 1 Remove the top cover 2 Begin to pull the tray by rotating the gear pulley (14)
clockwise. bottom view
3 Remove the tray panel.
14
tray panel
4 Remove the four screws which is fixing the dvd
mechanism to the chassis, and remove the mechanism from chassis.
How to disassembling the DVD mechanism 1 Remove the screw and remove the bridge (19). 3 Remove the tray by pressing down the stopper
SW lever (17).
19
stopper
screw
tray
2 Begin to pull the tray by rotating the gear pulley (14)
clockwise.
4 Set the pick short switch to short side.
[NOTE] Do not disconnect the FFC and wire before doing this work.
