DX-C390_En.book Page 11 Wednesday, August 27, 2003 5:49 PM
Before Using the DX-C390
Installing the Remote Controller�s Batteries Using the Remote Controller
To use the remote controller, point it at the DX-C390�s remote control sensor, as shown.
DX-C390
1
Remove the battery compartment cover, as shown.
Remote control sensor
30°
30°
Ap
ox pr
.1
6 ft
. (5
m
)
2
Insert the two supplied batteries (AA/R6) in accordance with the polarity diagram inside the battery compartment. Notes: � The remote controller may not work reliably if the DX-C390 is subjected to bright light, such as direct sunlight or inverter-type �uorescent lights. Keep this in mind when installing the DX-C390. � If another remote controller of the same type is used in the same room, or the DX-C390 is installed close to equipment that uses infrared rays, the remote controller may not work reliably. � Don�t put anything, such as a book, on the remote controller, because the buttons may be pressed inadvertently, thereby draining the batteries. � The remote controller may not work reliably if the DX-C390 is installed in a rack behind colored glass doors. Keep this in mind when installing the DX-C390. � The remote controller will not work if there�s an obstacle between it and the DX-C390�s remote control sensor.
3
Replace the battery compartment cover.
Notes: � The batteries should last for about six months, although this will vary with usage. � If the remote controller doesn�t work reliably, try replacing the batteries. � Don�t mix new and old batteries or different types of batteries. � If you intend not to use the remote controller for a long time, remove the batteries to prevent damage from leakage or corrosion. � Flat batteries should be removed as soon as possible to prevent damage from leakage or corrosion.
