Selecting the frequencies to be stored in the channel bank �U� (variable bank) � tunE
Via the �tunE� menu, you can freely select the frequencies to be stored in the channel bank �U� (variable bank). Via the �CHAn� menu, select the channel whose frequency you want to change. Note: The frequencies stored in the channel bank �F� (fixed bank) cannot be changed. When you have selected the channel bank �F� and then select the �tunE� menu, the receiver automatically switches to channel 01 of the channel bank �U� and �U.01� briefly appears on the LC display panel ¿. To change the frequency of the selected channel, press the button ´ or the button ². The frequencies are tunable in 5-kHz steps within a switching bandwidth of 36 MHz max.
Adjusting the squelch threshold � SquELH
Via the �SquELH� menu, you can adjust the squelch threshold. The squelch eliminates annoying noise during transmission pauses or when the received RF signal gets weaker. Notes: If the squelch threshold is adjusted too high, the transmission range will be reduced. Therefore, always adjust the squelch threshold to the lowest possible setting. When in the setting mode of the �SquELH� menu, pressing the button (DOWN) for more than three seconds will switch the squelch off. �Sql.off� appears on the display. If no RF signal is being received, hissing noise will occur. This setting is for test purposes only.
Activating/deactivating the automatic receiver switch-on/off via the camcorder � Auto
Via the �Auto� menu, you can activate or deactivate the automatic receiver switch-on/off via the camcorder. Setting Aut.on Aut.oFF Function Automatic receiver switch-on/off via the camcorder is activated Automatic receiver switch-on/off via the camcorder is deactivated
