x Using the joystick
1 Display the main MENU and select the menu you
want to adjust. Press the joystick once to display the main MENU. Then move the joystick up, down, left, or right to highlight the desired menu. Press the joystick to select the menu item.

Adjusting the brightness and contrast
Brightness and contrast adjustments are made using a separate BRIGHTNESS/CONTRAST menu. These settings are stored in memory for the signals from the currently selected input connector.

Adjusting the centering of the picture (CENTER)
This setting is stored in memory for the current input signal.

Adjusting the shape of the picture (GEOM)
The (rotation) setting is stored in memory for all input signals. All other settings are stored in memory for the current input signal.

1 Press the joystick.
The main MENU appears on the screen.

1 Press the joystick.
1 Move the joystick in any direction.

b

b

The BRIGHTNESS/CONTRAST menu appears on the screen.
BR I GHTNESS / CONTRAS T

2 Move the joystick to highlight

press the joystick again. The SIZE/CENTER menu appears on the screen.

CENTER and

The main MENU appears on the screen.

2 Move the joystick to highlight

3 First move the joystick up or down to select

26

26

for horizontal adjustment, or for vertical adjustment. Then move the joystick left or right to adjust the centering.

GEOM and press the joystick again. The GEOMETRY menu appears on the screen.

3 First move the joystick up or down to select the
desired adjustment item. Then move the joystick left or right to make the adjustment. Select To rotate the picture expand or contract the picture sides shift the picture sides to the left or right adjust the picture width at the top of the screen shift the picture to the left or right at the top of the screen

2 Adjust the menu.
Move the joystick up, down, left, or right to make the adjustment.

2 Move the joystick up or down to adjust the
brightness ( contrast (6).

), and left or right to adjust the

Adjusting the size of the picture (SIZE)
This setting is stored in memory for the current input signal.

If you select the sRGB mode in the COLOR menu
Confirm that the brightness ( ) and contrast (6) values are adjusted respectively to the numbers to be set in the sRGB mode shown in the BRIGHTNESS/CONTRAST menu. If not, press the RESET button (for less than 2 seconds).

1 Press the joystick.
The main MENU appears on the screen.

2 Move the joystick to highlight
joystick again.

SIZE and press the

GB

1-4

BR I GHTNESS / CONTRAS T

3 Close the menu.
Press the joystick once to return to the main menu, and twice to return to normal viewing. If no buttons are pressed, the menu closes automatically after about 30 seconds.
56 s RGB : 56 76 76

The SIZE/CENTER menu appears on the screen.
Values to be set in the sRGB mode

3 First move the joystick up or down to select

For more information about using the sRGB mode, see ìAdj usting the color of the picture (COLOR)î on page 11. The menu automatically disappears after about 3 seconds.

for horizontal adjustment, or for vertical adjustment. Then move the joystick left or right to adjust the size.

Adjusting the color of the picture (COLOR)
The COLOR settings allow you to adjust the pictureís color temperature by changing the color level of the white color field. Colors appear reddish if the temperature is low, and bluish if the temperature is high. This adjustment is useful for matching the monitorís color to a printed pictureís colors.

Enlarging or reducing the picture (ZOOM)
This setting is stored in memory for the current input signal.

x Resetting the adjustments
Press the RESET button. See page 15 for more information on resetting the adjustments.
RESET

1 Press the joystick.
The main MENU appears on the screen.

1 Press the joystick.

The main MENU appears on the screen. SIZE or CENTER and press the joystick again. The SIZE/CENTER menu appears on the screen.

2 Move the joystick to highlight

2 Move the joystick to highlight

COLOR and press the joystick again. The COLOR menu appears on the screen.

3 Move the joystick left or right to select the
adjustment mode. There are three types of adjustment modes, EASY, EXPERT, and sRGB. Adjust the selected mode according to the instructions on the next page. You can set the color temperature in EASY or EXPERT mode for each of the video input connectors.

3 Move the joystick up or down to select

(zoom), and move the joystick left or right to enlarge or reduce the picture.

Note Adjustment stops when either the horizontal or vertical size reaches its maximum or minimum value.

(continued)
