6. ADJUSTMENT
There is no information to be shown in this chapter.
A
7. GENERAL INFORMATION
7.1 DIAGNOSIS 7.1.1 DISASSEMBLY
- Removing the Case (not shown)
B
1. Remove the eight screws and then remove the Case.
- Removing the Amp Unit (Fig.1)
Panel
1 1 1 1
C
1 2 3 4
Remove the eight screws.
Remove the screw and then remove the two Panels. Remove the eight screws and then remove the two Heat Sinks. Remove the five screws and then remove the Amp Unit.
4 3
4 3
3 3 4
3 3
D
3
4
4
3
1 2 1
1 1
E
Heat Sink
Panel
Amp Unit Heat Sink
Fig.1
F
GM-X572/XR/UC
