5-5. CTL/TC Head Height Adjustment

Adjustment 7. In Case the Level Increases when the Tape is Pressed Down (Fig. 1) Turn the height adjustment screw clockwise and adjust so that the output waveform is maximum. 8. In Case the Level Increases when the Tape is Pushed Up (Fig. 2) Turn the height adjustment screw counterclockwise and adjust so that the output waveform is maximum. In case the adjustment is performed 9. Adjust the CTL/TC Head Azimuth Refer to Section 5-6.
Height adjustment screw

<Fig. 1>

10. Adjust the CTL/TC Head Position Refer to Section 5-7. 11. Check the CTL/TC Head Height Refer to steps 6 and 7 in this section. 12. Check the CTL/TC Head Azimuth Refer to Section 5-6.

maximize

<Fig. 2>

Height adjustment screw

maximize

CTL/TC Head Height Adjustment

5-24

GY-2120WD/WS
