SONY HCD-CQ1
Instrukcja Serwisowa

HCD-CQ1 SECTION 3 DISASSEMBLY
� The equipment can be removed using the following procedure.
SET

PANEL (BACK)

PANEL (TOP) ASSY

CD MECHANISM DECK (CDM76-K6BD44S)

PANEL BOARD

JACK BOARD, REG BOARD

BEARING ASSY, BUSHING (GUIDE A)

OPTICAL PICK-UP (KSM-213DCP/Z-NP)

TRAY

SLIDER (R), SLIDER (L)

TUNER (FM/AM)

BD BOARD

LOADING BOARD, GEAR (P), GEAR (M)

POWER BOARD

KSS-213D/Q-RP

REMOCON BOARD, PANEL (FRONT) ASSY

CONTROL BOARD

Note : Follow the disassembly procedure in the numerical order given.

3-1. Panel (Back)
3 panel (back) 1 three screws (+BVTP 3 �10) 4 panel (back) top 2 six screws

(+BVTP 3 � 8)

Note When removing the panel (back), do not remove this screw. (This screw fastens the tuner (FM/AM) pack.)

9
