HCD-HPX9
4-3. ASSEMBLING OF THE GEAR (STOCK ROT SHORT) (RIGHT)
7 two screws (2 � 6) 8 screw (1.7)
Note: Install the stock box (R) right after finishing the phase adjustment.
6 stock box (R)
short
4 gear (stock rot short) 2 gear (stock rot short)
UPPER SIDE
PRECAUTION DURING GEAR (STOCK ROT SHORT) INSTALLATION 1 Align the edges of the stockers. Keep the position of the stockers until finishing installation of the gear (stock rot short) and the stock box (R).
FRONT SIDE
gear (stock rot short)
3 Adjusting the one stockers
