2-WAY 2-SPEAKER SYSTEM

LS-M51
SERVICE MANUAL (HM-531)
EXTERNAL VIEW
Grille holder (J19-3964-05)x4 Binding head tapping screw (N44-4030-45)x4 Panel assy (with tweeter) (A29-0932-08)

©1998-8/B51-5459-00 (Z/K)656

Dressing panel (A21-3150-08)

Woofer (T10-0860-05)

Terminal (E21-0297-05) Grille assy (B06-1291-08)

SPECIFICATIONS
Enclosure ............................................................................................Bass-reflex,Book shelf type Woofer ..................................................................................................100 mm, (4 in) cone type Tweeter................................................................................................35 mm, (1.5 in) cone type Impedance ...............................................................................................................................6 � Maximum input level............................................................................................................30 W Frequency response ........................................................................................50 Hz ~ 20,000 Hz Dimensions W:140mm (5-1 / 2") H: 245mm (9-5 / 8") D: 225mm (8-7 / 8") Net Weight ...................................................................................................2.3 kg (5.0 lb / piece)

Note: KENWOOD follows a policy of continuous advancements in development. For this reason specifications may be changed without notice.
