ADJUSTMENT
<RADIO SECTION>
1. AM IF Adjustment L205 ...................................................................... 450 kHz 2. AM VT Check Settings : � Test point : TP1 (VT) Method : Set to AM 530 kHz, and check that the test point is 1.0 V ± 0.3 V. Then set to AM 1710 kHz, and check that the test point is less than 9.0V. 3. FM VT Check Settings : � Test point : TP1 (VT) Method : Set to FM 87.5 MHz, and check that the test point is 4.0 V ± 0.1 V. Then set to FM 108.1 MHz, and check that the test point is less than 9.0V. 4. AM Tracking Adjustment L203 ...................................................................... 630 kHz TC201 .................................................................. 1440 kHz 5. FM Tracking Adjustment L201 .................................................................... 87.5 MHz
<TAPE PLAYER SECTION>
6. Tape Speed Adjustment Settings : � Test tape : TTA�100 � Test point : Phones Jack (J101) � Volume : MAX � S-Bass : OFF �Tape selector : Normal � Adjustment location : SFR401 Method : Play back the test tape and adjust SFR401 for 3015 Hz ± 10 Hz (FWD). Then confirm WOW is less than 0.52%. 7. Head Azimuth Adjustment Settings : � Test tape : TTA�320/TTA�330 � Test point : Phones Jack (J101) � Volume : MAX � S-Bass : OFF �Tape selector : Normal � Adjustment location : Head azimuth adjustment screw Method : Play back the 8 kHz signal of the test tape and adjust the screw so that the output becomes maximum.
