ONKYO HTP8230
Instrukcja Serwisowa

TDA7293
The TDA7293 is a monolithic MOS power amplifier which can be operated at 100V supply voltage (120V with no signal applied) while delivering output currents up to ±6.5 A. This allows the use of this device as a very high power amplifier (up to 180W as peak power with T.H.D.=10 % and Rl = 4 Ohm); the only drawback is the power dissipation, hardly manageable in the above power range. The typical junction-to-case thermal resistance of the TDA7293 is 1 oC/W (max= 1.5 oC/W). To avoid that, in worst case conditions, the chip temperature exceedes 150 oC, the thermal resistance of the heatsink must be 0.038 oC/W (@ max ambient temperature of 50 oC). As the above value is pratically unreachable; a high efficiency system is needed in those cases where the continuous RMS output power is higher than 50-60 W. The TDA7293 was designed to work also in higher efficiency way. For this reason there are four power supply pins: two intended for the signal part and two for the power part. T1 and T2 are two power transistors that only operate when the output power reaches a certain threshold (e.g. 20 W). If the output power increases, these transistors are switched on during the portion of the signal where more output voltage swing is needed, thus "bootstrapping" the power supply pins (#13 and #15). The current generators formed by T4, T7, zener diodes Z1, Z2 and resistors R7,R8 define the minimum drop across the power MOS transistors of the TDA7293. L1, L2, L3 and the snubbers C9, R1 and C10, R2 stabilize the loops formed by the "bootstrap" circuits and the output stage of the TDA7293. By considering again a maximum average output power (music signal) of 20W, in case of the high efficiency application, the thermal resistance value needed from the heatsink is 2.2 oC/W (Vs =±50 V and Rl= 8 Ohm). All components (TDA7293 and power transistors T1 and T2) can be placed on a 1.5 oC/W heatsink, with the power darlingtons electrically insulated from the heatsink. Since the total power dissipation is less than that of a usual class AB amplifier, additional cost savings can be obtained while optimizing the power supply, even with a high heatsink . BRIDGE APPLICATION Another application suggestion is the BRIDGE configuration, where two TDA7293 are used. In this application, the value of the load must not be lower than 8 Ohm for dissipation and current capability reasons. A suitable field of application includes HI-FI/TV subwoofers realizations.
8/15

The main advantages offered by this solution are: - High power performances with limited supply voltage level. - Considerably high output power even with high load values (i.e. 16 Ohm). With Rl= 8 Ohm, Vs = ±25V the maximum output power obtainable is 150 W, while with Rl=16 Ohm, Vs = ±40V the maximum Pout is 200 W. APPLICATION NOTE: (ref. fig. 7) Modular Application (more Devices in Parallel) The use of the modular application lets very high power be delivered to very low impedance loads. The modular application implies one device to act as a master and the others as slaves. The slave power stages are driven by the master device and work in parallel all together, while the input and the gain stages of the slave device are disabled, the figure below shows the connections required to configure two devices to work together. The master chip connections are the same as the normal single ones. The outputs can be connected together without the need of any ballast resistance. The slave SGND pin must be tied to the negative supply. The slave ST-BY and MUTE pins must be connected to the master ST-BY and MUTE pins. The bootstrap lines must be connected together and the bootstrap capacitor must be increased: for N devices the boostrap capacitor must be 22µF times N. The slave IN-pin must be connected to the negative supply. THE BOOTSTRAP CAPACITOR For compatibility purpose with the previous devices of the family, the boostrap capacitor can be connected both between the bootstrap pin (6) and the output pin (14) or between the boostrap pin (6) and the bootstrap loader pin (12). When the bootcap is connected between pin 6 and 14, the maximum supply voltage in presence of output signal is limited to 100V, due the bootstrap capacitor overvoltage. When the bootcap is connected between pins 6 and 12 the maximum supply voltage extend to the full voltage that the technology can stand: 120V. This is accomplished by the clamp introduced at the bootstrap loader pin (12): this pin follows the output voltage up to 100V and remains clamped at 100V for higher output voltages. This feature lets the output voltage swing up to a gate-source voltage from the positive supply (VS -3 to 6V).
