EXPLODED VIEW
NOTE: � -XX, -X mean standardized parts, so they may have some differences from the original one. � Items marked �*� are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. � � The mechanical parts with no reference number in the exploded views are not supplied. Hardware (# mark) list and accessories and packing materials are given in the last of this parts list.
When indicating parts by reference number, please include the board name.
UPPER LID BLOCK ASSY, CASE BLOCK ASSY
3
20
SP101
2
15
ND701
16
6 7
D503
5 19 17
8
MIC101
9 12 10
18
14 13
4 1 11
Ref. No. *1 2 3 4 5 6 7 8 9 10 11 12
Part No. A-3293-775-A 4-995-845-03 X-4949-181-1 4-997-709-01 4-995-841-02 3-318-382-61 1-475-434-11 4-995-839-12 3-318-203-95 4-995-842-01
Description
Remarks
Ref. No. 13 14 15 16 17 18 19 20 D503 ND701 SP101
Part No. 4-995-843-01 4-995-844-01 4-998-440-01 4-998-809-01 4-998-824-01 4-998-806-01 4-998-748-01 3-951-345-01 1-517-711-11 1-801-928-11
Description TERMINAL (+), BATTERY TERMINAL (�), BATTERY SPACER (WINDOW) CUSHION (BUTTON) SHEET (W) SHEET (SD) SPRING (A) CUSHION, PANEL LIGHT, LED BACK INDICATOR MODULE
Remarks
MAIN PC BOARD ASSY BOARD, COMPLETE SPRING (SPEAKER) LID ASSY, UPPER SHEET (P) CAP (PC) SCREW (1.7X2.5), TAPPING SWITCH UNIT (WITH JOG DIAL) CASE SCREW (B1.7), TAPPING TERMINAL (+ �), BATTERY
4-995-840-02 LID, BATTERY CASE 3-928-815-11 STRAP, HAND
1-505-854-11 SPEAKER (2.8CM)
�2�
|
