CHAPTER 10 SIDE PAPER DECK

3) Take out the compartment from the deck. (See p. 10-28.) 4) Disconnect the connector [5], and remove the five screws [6]; then, detach the deck lifter motor unit [7].

[5]

[6]

[7]
Figure 10-C306 5. Removing the Lifter Cable (front of the deck) 1) Open the compartment of the deck, and remove all paper. 2) Remove the screw, and detach the paper trailing edge guide plate from inside the compartment. 3) Push the lever [1] of the paper supply position sensor inside the compartment to move down the lifter; when the holes on the left and right of the compartment side plate and the holes on the left and right of the lifter match, insert two long screwdrivers [2] through the holes to hold the lifter in position.

[6]

[1]

[2] Figure 10-C307

10-34
