TUNER OPERATIONS
POWER STANDBY / ON ENTER MULTI JOG TUNER BAND
Tuning in to preset stations
BAND TUNER MEMORY TUNER MODE
On the unit 1 Press TUNER BAND to select a band.
2 Turn MULTI JOG.
The station with the previous/succeeding preset number is tuned in.
ENTER
On the remote 1 Press SHIFT+BAND to select a band.
SHIFT CLEAR
2 Press r or t repeatedly to select the desired station.
Adjustments Manual tuning
1 Press TUNER BAND (SHIFT+BAND on the remote) repeatedly to select a band (FM or AM.) 2 Press f or g to tune in to a station.
�TUNED� appears when a station is tuned in. �1� lights up for FM stereo reception. To search for a station automatically (Auto Search) Hold down f or g. The unit searches for a station up or down the band and stops at reception. To stop the search manually, press f or g. �Auto Search may not stop at stations with weak signals.
En
Preset tuning
Preset up to 30 of your favorite stations (20 FM and 10 AM) and tune them in directly.
Presetting stations
1 Press TUNER BAND to select a band. 2 Press f or g to tune in to the desired station. 3 Press SHIFT+TUNER MEMORY on the remote to store the station.
The preset number, beginning from �1�, appears in the display.
Antennas Keep antennas away from metallic objects, electrical equipment and cords. FM antenna: Extend fully and position for the best reception. If receiving condition is poor, connect optional outdoor antenna to FM 75 � terminal. Use an adapter as required. AM antenna: Rotate to find best reception. To switch to monaural FM reception Press SHIFT+TUNER MODE on the remote. With each press, �MONO� and �1� appear alternately in the display. Tip: When FM stereo reception is poor, switching to monaural reduces noise. To switch the AM tuning interval Hold down POWER and press ENTER on the unit. With each press, the AM tuning interval alternates between 9 kHz/step and 10 kHz/step.
4 Press r or t on the remote to select a preset number and press ENTER to set the number. 5 Repeat step 1 to 4 to preset other stations.
Tip: The default is 10 kHz/step. Change it only when using the unit in a 9 kHz/step area. Switching AM tuning interval clears all the preset stations.
